Deploying LiteLLM in Kubernetes with HashiCorp Vault Secrets

LiteLLM + HashiCorp Vault

AI Gateway with Dynamic Secrets in Kubernetes

Deploy LiteLLM as an AI proxy using HashiCorp Vault for dynamic secrets management, PostgreSQL persistence, and Kubernetes orchestration for production-grade AI infrastructure.

Why HashiCorp Vault?

While deploying LiteLLM in my Kubernetes infrastructure, I realized this was the perfect opportunity to showcase HashiCorp Vault integration. LiteLLM requires multiple sensitive credentials – OpenAI API keys, Anthropic tokens, database passwords, and master keys – making it an ideal candidate for demonstrating proper secrets management rather than stuffing everything into plain Kubernetes secrets.

The Problem: AI applications often need multiple high-value API keys that should be rotated regularly, audited, and controlled. Traditional secrets management doesn’t give you the granular control needed for production deployments.

HashiCorp Vault provides dynamic secrets, automatic rotation, detailed audit logs, and policy-based access control. Since I was deploying LiteLLM anyway, it seemed like the perfect opportunity to showcase proper secrets management in action.

Prerequisites

Required Infrastructure

This guide assumes you have existing infrastructure components. We’ll focus on LiteLLM deployment rather than setting up these foundational systems.

⚓ Kubernetes Cluster

Running cluster with ingress controller (Traefik/Nginx) and persistent storage. We’ll use the ‘ai-services’ namespace.

🔐 HashiCorp Vault

Running Vault instance with Kubernetes authentication configured. Access to create policies and manage secrets paths.

🗄️ PostgreSQL Database

PostgreSQL instance for LiteLLM data persistence. Could be managed service or self-hosted cluster with TLS enabled.

Vault Configuration

Vault Setup Commands

First, create the secrets engine, store your credentials, and configure External Secrets Operator authentication.

# Step 1: Enable KV secrets engine for LiteLLM
vault secrets enable -path=litellm kv-v2

# Step 2: Create secrets for LiteLLM
vault kv put litellm/api-keys \
  master-key="sk-your-secure-master-key" \
  salt-key="sk-your-secure-salt-key" \
  openai-key="sk-your-openai-api-key" \
  anthropic-key="sk-your-anthropic-api-key"

vault kv put litellm/database \
  url="postgresql://litellm:password@postgres:5432/litellm?sslmode=require"

# Step 3: Create policy for External Secrets Operator
vault policy write eso-litellm-policy - <



External Secrets Operator


    Dynamic Secrets Integration
    External Secrets Operator (ESO) synchronizes secrets from Vault to Kubernetes, providing automatic updates and rotation without redeploying pods.


# Install External Secrets Operator
helm repo add external-secrets https://charts.external-secrets.io
helm install external-secrets external-secrets/external-secrets \
  --namespace external-secrets-system --create-namespace

Service Account and SecretStore

# Vault Token Secret (create this first)
apiVersion: v1
kind: Secret
metadata:
  name: vault-token
  namespace: ai-services
type: Opaque
stringData:
  token: your-vault-token-here
---
# SecretStore with token authentication
apiVersion: external-secrets.io/v1
kind: SecretStore
metadata:
  name: vault-backend
  namespace: ai-services
spec:
  provider:
    vault:
      server: "https://vault.example.com:8200"
      path: "secret"
      version: "v2"
      auth:
        tokenSecretRef:
          name: "vault-token"
          key: "token"


    Authentication Method
    This setup uses token-based authentication for simplicity. While Kubernetes authentication provides better security through service account integration, token auth is easier to set up and manage for initial deployments. I'll cover Kubernetes authentication setup in a separate post.


ExternalSecret Resource

# ExternalSecret for LiteLLM credentials
apiVersion: external-secrets.io/v1beta1
kind: ExternalSecret
metadata:
  name: litellm-secrets
  namespace: ai-services
spec:
  refreshInterval: 15s
  secretStoreRef:
    name: vault-backend
    kind: SecretStore
  target:
    name: litellm-secrets
    creationPolicy: Owner
  data:
  # API Keys from Vault
  - secretKey: LITELLM_MASTER_KEY
    remoteRef:
      key: litellm/api-keys
      property: master-key
  - secretKey: LITELLM_SALT_KEY
    remoteRef:
      key: litellm/api-keys
      property: salt-key
  - secretKey: OPENAI_API_KEY
    remoteRef:
      key: litellm/api-keys
      property: openai-key
  - secretKey: ANTHROPIC_API_KEY
    remoteRef:
      key: litellm/api-keys
      property: anthropic-key
  # Database connection from Vault
  - secretKey: DATABASE_URL
    remoteRef:
      key: litellm/database
      property: url

LiteLLM Deployment


    Production-Ready Setup
    The deployment uses secrets from Vault, includes health checks, and configures PostgreSQL persistence with automatic database migration.


# LiteLLM Deployment with Vault secrets
apiVersion: apps/v1
kind: Deployment
metadata:
  name: litellm
  namespace: ai-services
spec:
  replicas: 2
  selector:
    matchLabels:
      app: litellm
  template:
    metadata:
      labels:
        app: litellm
    spec:
      containers:
      - name: litellm
        image: ghcr.io/berriai/litellm:main-stable
        ports:
        - containerPort: 4000
        env:
        # Database configuration
        - name: DATABASE_URL
          valueFrom:
            secretKeyRef:
              name: litellm-secrets
              key: DATABASE_URL
        - name: STORE_MODEL_IN_DB
          value: "True"
        - name: RUN_MIGRATION
          value: "True"
        # Authentication keys from Vault
        - name: LITELLM_MASTER_KEY
          valueFrom:
            secretKeyRef:
              name: litellm-secrets
              key: LITELLM_MASTER_KEY
        - name: LITELLM_SALT_KEY
          valueFrom:
            secretKeyRef:
              name: litellm-secrets
              key: LITELLM_SALT_KEY
        # AI Provider API keys from Vault
        - name: OPENAI_API_KEY
          valueFrom:
            secretKeyRef:
              name: litellm-secrets
              key: OPENAI_API_KEY
        - name: ANTHROPIC_API_KEY
          valueFrom:
            secretKeyRef:
              name: litellm-secrets
              key: ANTHROPIC_API_KEY
        # Health checks
        livenessProbe:
          httpGet:
            path: /health/liveliness
            port: 4000
          initialDelaySeconds: 40
          periodSeconds: 30
        readinessProbe:
          httpGet:
            path: /health/readiness
            port: 4000
          initialDelaySeconds: 10
          periodSeconds: 5
        # Resource limits
        resources:
          requests:
            memory: "512Mi"
            cpu: "200m"
          limits:
            memory: "1Gi"
            cpu: "1000m"

Service & Ingress

Service Configuration

# LiteLLM Service
apiVersion: v1
kind: Service
metadata:
  name: litellm-service
  namespace: ai-services
spec:
  selector:
    app: litellm
  ports:
  - port: 4000
    targetPort: 4000
    name: http
  type: ClusterIP

Ingress with TLS

# LiteLLM Ingress
apiVersion: networking.k8s.io/v1
kind: Ingress
metadata:
  name: litellm-ingress
  namespace: ai-services
  annotations:
    kubernetes.io/ingress.class: "nginx"
    cert-manager.io/cluster-issuer: "letsencrypt-prod"
    nginx.ingress.kubernetes.io/ssl-redirect: "true"
spec:
  tls:
  - hosts:
    - litellm.example.com
    secretName: litellm-tls
  rules:
  - host: litellm.example.com
    http:
      paths:
      - path: /
        pathType: Prefix
        backend:
          service:
            name: litellm-service
            port:
              number: 4000

Verification & Testing


    Deployment Validation
    Verify that your LiteLLM deployment is running correctly with Vault secrets integration and database connectivity.


# Check ExternalSecret synchronization
kubectl get externalsecret -n ai-services
kubectl describe externalsecret litellm-secrets -n ai-services

# Verify secrets are created
kubectl get secrets -n ai-services
kubectl describe secret litellm-secrets -n ai-services

# Check LiteLLM pods
kubectl get pods -n ai-services
kubectl logs -n ai-services deployment/litellm

# Test health endpoints
kubectl port-forward -n ai-services svc/litellm-service 4000:4000
curl http://localhost:4000/health

# Test via ingress
curl https://litellm.example.com/health
curl https://litellm.example.com/docs


    API Testing
    Test the LiteLLM API with your master key:
    curl -X POST https://litellm.example.com/v1/chat/completions \
  -H "Authorization: Bearer YOUR_MASTER_KEY" \
  -H "Content-Type: application/json" \
  -d '{
    "model": "gpt-3.5-turbo",
    "messages": [{"role": "user", "content": "Hello!"}]
  }'


Security Benefits



        Dynamic Secrets

            Automatic secret rotation without redeployment
            Short-lived tokens with configurable TTL
            Centralized secrets management
            No secrets hardcoded in manifests




        Access Control

            Policy-based access to secrets
            Service account authentication
            Namespace isolation
            Principle of least privilege




        Audit & Compliance

            Complete audit trail of secret access
            Encryption at rest and in transit
            Integration with monitoring systems
            Compliance with security standards





    Secure AI Infrastructure
    You now have LiteLLM running in Kubernetes with proper secrets management via HashiCorp Vault. This setup gives you dynamic secrets, automatic rotation, policy-based access control, and comprehensive audit trails - everything you need for production AI workloads handling sensitive API keys and user data.

    The External Secrets Operator bridge keeps your secrets synchronized while maintaining Kubernetes-native workflows. Your AI infrastructure is now ready for production deployment with proper security controls.



            🔒 Secure • 📈 Scalable • 🚀 Production-Ready
